| SW- |
| »úÐÍ Type | 80DY | 110DY | 150DY | 160DY | 200DY | 210DY | 250DY | 260DY | 280DY | 310DY |
ÃûÒåÖÆÀäÁ¿
Nominal cooling capacity | kW | 80.0 | 110.0 | 150.0 | 160.0 | 200.0 | 210.0 | 250.0 | 260.0 | 280.0 | 310.0 |
| 104kcal/h | 6.9 | 9.5 | 12.9 | 13.8 | 17.2 | 18.1 | 21.5 | 22.4 | 24.1 | 26.7 |
| ÔËÐпØÖÆ·½Ê½ Run control | PLC¿É±à³Ì¿ØÖÆÆ÷È«×Ô¶¯¿ØÖÆ Use PLC microcomputer control |
| µçÔ´ Power Supply | 380V/3N/50HZ |
| Æô¶¯ÀàÐÍ Startup type | Y-¡÷ |
| ѹËõ»úCompressor | ÐÍʽ Type | 5:6·Ç¶Ô³Æ°ë·â±ÕË«ÂݸËѹËõ»ú Semi-closed 5:6 asymmetric twin-screw compressor |
ÊäÈ빦ÂÊ(kW)
Refrigeration input power | 38.0 | 50.0 | 60.0 | 68.0 | 84.0 | 90.0 | 100.0 | 106.0 | 116.0 | 128.0 |
| ¶î¶¨µçÁ÷(A) Rated Current | 65.8 | 86.6 | 108.8 | 119.2 | 145.2 | 158.2 | 178.0 | 187.2 | 206.2 | 224.8 |
| ÄÜÁ¿µ÷½Ú Energy regulation | 0-16.5%-33%-...100% | 0-12.5%-25%-37.5%-...100% |
| Õô·¢Æ÷Evaporator | ÐÍʽ Type | ¸ßЧ¿Ç¹Ü¸Éʽ»»ÈÈÆ÷ Pipe dry high efficiency heat exchanger |
| Ë®Á÷Á¿(m3/h) Flow | 16.1 | 22.1 | 30.2 | 32.2 | 40.2 | 42.2 | 50.3 | 52.3 | 56.3 | 62.3 |
| ˮѹ½µ(kPa) Water pressure drop | 50.0 | 50.0 | 54.0 | 54.0 | 58.0 | 58.0 | 60.0 | 60.0 | 63.0 | 63.0 |
| Åä¹Ü¹Ü¾¶(mm) Interface size | DN50 | DN65 | DN80 | DN100 |
| ÀäÄýÆ÷Condenser | ÐÍʽ Type | ¸ßЧ¿Ç¹Üʽ»»ÈÈÆ÷ Pipe high efficiency heat exchanger |
| Ë®Á÷Á¿(m3/h) Flow | 20.3 | 27.5 | 36.1 | 39.2 | 48.8 | 51.6 | 60.2 | 63.0 | 66.4 | 75.3 |
| ˮѹ½µ(kPa) Water pressure drop | 45.0 | 45.0 | 48.0 | 48.0 | 52.0 | 52.0 | 55.0 | 55.0 | 58.0 | 58.0 |
| Åä¹Ü¹Ü¾¶(mm) Interface size | DN65*2 | DN80*2 | DN100*2 |
| ÖÆÀä¼ÁRefrigerant | ÀàÐÍ Type | R22 |
| ³ä×¢Á¿(kg) Refrigerant volume | 20.5 | 28.1 | 38.4 | 40.9 | 51.2 | 53.7 | 64.0 | 66.5 | 71.6 | 79.3 |
ÍâÐγߴç
Overall dimensions | ³¤(mm) Length | 3570 | 3570 | 3570 | 3570 | 3570 | 3570 | 3570 | 3570 | 3570 | 4100 |
| ¿í(mm) Width | 1050 | 1100 | 1190 | 1190 | 1240 | 1280 | 1320 | 1320 | 1380 | 1400 |
| ¸ß(mm) Height | 1530 | 1530 | 1540 | 1580 | 1650 | 1650 | 1650 | 1650 | 1700 | 2100 |
| ÖØÁ¿ weight | »ú×éÂÔÖØ(kg) Machine weight | 1500 | 1700 | 1950 | 2150 | 2250 | 2450 | 2850 | 2900 | 3050 | 3500 |
| ÔËÐÐÂÔÖØ(kg) Operating weight | 1785 | 2035 | 2435 | 2535 | 2620 | 2970 | 3410 | 3460 | 3680 | 3930 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| SW- |
| »úÐÍ Type | 340DY | 400DY | 420DY | 460DY | 500DY | 520DY | 600DY | 660DY | 720DY | 800DY |
ÃûÒåÖÆÀäÁ¿
Nominal cooling capacity | kW | 340.0 | 400.0 | 420.0 | 460.0 | 500.0 | 520.0 | 600.0 | 660.0 | 720.0 | 800.0 |
| 104kcal/h | 29.2 | 34.4 | 36.1 | 39.6 | 43.0 | 44.7 | 51.6 | 56.7 | 61.9 | 68.8 |
| ÔËÐпØÖÆ·½Ê½ Run control | PLC¿É±à³Ì¿ØÖÆÆ÷È«×Ô¶¯¿ØÖÆ Use PLC microcomputer control |
| µçÔ´ Power Supply | 380V/3N/50HZ |
| Æô¶¯ÀàÐÍ Startup type | Y-¡÷ |
| ѹËõ»úCompressor | ÐÍʽ Type | 5:6·Ç¶Ô³Æ°ë·â±ÕË«ÂݸËѹËõ»ú Semi-closed 5:6 asymmetric twin-screw compressor |
ÊäÈ빦ÂÊ(kW)
Refrigeration input power | 142.0 | 164.0 | 174.0 | 188.0 | 202.0 | 210.0 | 246.0 | 272.0 | 290.0 | 320.0 |
| ¶î¶¨µçÁ÷(A) Rated Current | 250.2 | 290.4 | 306.6 | 332.2 | 357.6 | 369.0 | 425.2 | 471.8 | 501.0 | 563.4 |
| ÄÜÁ¿µ÷½Ú Energy regulation | 0-12.5%-25%-37.5%-...100% |
| Õô·¢Æ÷Evaporator | ÐÍʽ Type | ¸ßЧ¿Ç¹Ü¸Éʽ»»ÈÈÆ÷ Pipe dry high efficiency heat exchanger |
| Ë®Á÷Á¿(m3/h) Flow | 68.3 | 80.4 | 84.4 | 92.5 | 100.5 | 104.5 | 120.6 | 132.7 | 144.7 | 160.8 |
| ˮѹ½µ(kPa) Water pressure drop | 65.0 | 75.0 | 80.0 | 85.0 | 85.0 | 90.0 | 90.0 | 95.0 | 110.0 | 115.0 |
| Åä¹Ü¹Ü¾¶(mm) Interface size | DN100 | DN125 | DN150 | DN200 |
| ÀäÄýÆ÷Condenser | ÐÍʽ Type | ¸ßЧ¿Ç¹Üʽ»»ÈÈÆ÷ Pipe high efficiency heat exchanger |
| Ë®Á÷Á¿(m3/h) Flow | 82.9 | 97.0 | 102.2 | 111.5 | 120.7 | 125.6 | 145.5 | 160.3 | 173.7 | 192.6 |
| ˮѹ½µ(kPa) Water pressure drop | 58.0 | 60.0 | 60.0 | 60.0 | 65.0 | 65.0 | 70.0 | 70.0 | 72.0 | 74.0 |
| Åä¹Ü¹Ü¾¶(mm) Interface size | DN100*2 | DN125*2 | DN150*2 |
| ÖÆÀä¼ÁRefrigerant | ÀàÐÍ Type | R22 |
| ³ä×¢Á¿(kg) Refrigerant volume | 87.0 | 102.3 | 107.5 | 117.7 | 127.9 | 133.1 | 153.5 | 168.9 | 184.2 | 204.7 |
ÍâÐγߴç
Overall dimensions | ³¤(mm) Length | 4100 | 4100 | 4500 | 4500 | 4500 | 4500 | 4500 | 4500 | 4900 | 4900 |
| ¿í(mm) Width | 1400 | 1400 | 1450 | 1500 | 1500 | 1500 | 1550 | 1550 | 1550 | 1550 |
| ¸ß(mm) Height | 2150 | 2150 | 2380 | 2400 | 2400 | 2400 | 2470 | 2470 | 2470 | 2470 |
| ÖØÁ¿ weight | »ú×éÂÔÖØ(kg) Machine weight | 3750 | 4250 | 5050 | 5750 | 5850 | 6550 | 6850 | 7850 | 7950 | 8100 |
| ÔËÐÐÂÔÖØ(kg) Operating weight | 4170 | 4670 | 5650 | 6350 | 6385 | 7135 | 7435 | 8485 | 8685 | 8885 |
